TSW200 INDUSTRIAL POE+ ETHERNET SWITCH (Profinet enabled)
TSW200 is an industrial Ethernet switch with 2 SFP ports for long-range Fiber-optic communication and 8 Gigabit Ethernet ports that support IEEE802.af and IEE802.3at Power-over-Ethernet standards. Classified as power source equipment (PSE), it enables the centralization of the power supply, providing up to 30 watts per port and reducing the effort to install power.
Beskrivelse
8 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
2 x SFP ports
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az, 802.3z
Profinet Class A conformance (available with optional order code)
Port 1 – 8
IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2), Alternative A (From batch 42)
IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2), Alternative B (From batch 1-41)
30 W
240 W
Short-circuit and overload protection
20 Gbps
128 KB
2K entries
9216 bytes
2-pin industrial DC power socket
7 – 57 VDC, reverse polarity protection: -80Vmax
44 – 57 VDC
Idle: 1.81 W / Max: 5.5 W / PoE Max: 245.5 W
Surge at AC mains power port**: 1kV Line to line; 2kV line to ground, 1.2/50us, IEC 61000-4-5
Surge at signal port (Ethernet): 1kV Line to Ground, 1.2/50us, IEC 61000-4-5
**Tested with Teltonika’s PSU. Test does not apply to direct DC power.
8 x RJ45 ports, 10/100/1000 Mbps
2 x SFP ports
1 x Power LED, 16 x ETH status LEDs 2 x SFP status LEDs
1 x 2-pin industrial DC power socket
1 x Grounding screw
Full aluminium housing
132 x 44.2 x 95.1 mm
517 g
Integrated DIN rail bracket; wall mount and flat surface (additional kit needed)
-40 °C to 75 °C
5% to 95% non-condensing
IP30
CE, UKCA, CITC, ANRT, FCC, IC, CB, MTCTE
EN 55032:2015 + A1:2020
EN 55035:2017 + A11:2020
EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A1:2019
EN 61000-4-2:2009
EN IEC 61000-4-3:2020
EN 61000-4-4:2012
EN 61000-4-5:2014 + A1:2017
EN 61000-4-6:2014
EN IEC 61000-4-11:2020
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
